An extensive range of scopes to suit all calibres and disciplines.
All Vantage riflescopes feature our H2 optics in a variety of configurations.
IR models feature precision glass etched reticles with multi-stage illumination in both red and green.
- Capped Low-Profile Turrets
- 1 Inch Mono-tube chassis
- Adjustable Objective For Parallax Correction
- Illumination
- 11 layer Fully Multi-Coated lenses
- High torque zoom ring
- Fast focus eyebell
Nitrogen purged. Shockproof. Waterproof. Fog proof.
All calibre rated.
Hawke No-Fault Lifetime Warranty.
Product Type
Riflescope
Product Range
Vantage IR
Objective Lens
40mm
Reticle
Rimfire .17 HMR (12x)
Parallax
Adjustable Objective
Magnification
4 - 12x
Optical System
System H2
Focal Plane
SFP (Second Focal Plane)
Scope Tube
1 Inch
Illumination
5 Levels - Red/Green
Field of View (ft@100yds)
26.2 - 8.7
Field of View (m@100m)
8.7 - 2.9
Field of View (°)
5 - 1.7
Eye Relief (in)
3.5
Eye Relief (mm)
90
PX/Focus (yds)
10 - ∞
PX/Focus (m)
9 - ∞
Exit Pupil (mm)
10 - 3.3
Exit Pupil (in)
0.39 - 0.13
Turret Type
Capped
Turret Caps
YES
Click Value
1/4 MOA
Elevation Turret Clicks (max)
80 MOA
Windage Turret Clicks (max)
80 MOA
Ocular Type
Fast Focus
Power Selector
Knurled Posi-Grip
Lens Coating
Fully Multi-Coated - 11 Layers
Length (in)
13.6
Length (mm)
346
Weight (oz)
18.1
Weight (g)
513
